Cast Steel Valve
Shanxi Solid Industrial Co., Ltd. (SOLID) is a cast steel valve manufacturer and supplier in China. We supply API and DIN industrial valves for oil and gas, petrochemical, power generation, water treatment and general pipeline projects: gate valves, globe valves, ball valves, swing check valves, dual plate check valves and butterfly valves.
Cast steel valve specs
Valve types: gate, globe, ball, swing check, dual plate check, butterfly
Sizes: 1/2"-48" (API) and DN15-DN1000 (DIN), depending on valve type
Pressure classes: ASME Class 150 / 300 / 600 / 900 / 1500; Class 2500 for applicable custom designs; DIN PN16-PN64
Body materials: ASTM A216 WCB, A352 LCB, A217 WC6 / WC9, A351 CF8 / CF8M / CF3 / CF3M; WCC, LCC, C5, C12, duplex and nickel alloys on request
Design standards: API 600, API 6D, API 594, API 609, ASME B16.34, BS 1873, BS 1868, BS 5351, DIN 3202
Ends: flanged (RF / RTJ), butt weld, wafer, lug
Operation: handwheel, lever, gear, electric actuator, pneumatic actuator
Testing: API 598 for applicable API models; DIN 3230 for DIN check valves
Supply: wholesale, mixed-valve project orders, OEM manufacturing to customer drawings
SOLID serves distributors, EPC contractors and industrial equipment manufacturers who want to buy several valve types, materials and pressure classes from one supplier. Send us your valve list and we will quote it as a single order.
Product Type | Size | Pressure Rating | Main Features |
|---|---|---|---|
1/2"-48" | Class 150-1500 | Bolted bonnet, OS&Y, rising stem, flanged or butt-weld ends | |
1/2"-24" | Class 150-1500 | Bolted bonnet, flow regulation, multiple trim options | |
1/2"-24" | Class 150-1500 | Floating or trunnion-mounted ball, two-piece or three-piece body | |
1/2"-40" | Class 150-1500 | Bolted cover, swing disc, flanged or butt-weld ends | |
2"-32" | Class 150-1500 | Wafer body, dual plate, spring-assisted closure | |
2"-80" | Class 150-1500 | Wafer, lug and flanged configurations | |
DN15-DN300 | PN16 / 25 / 40 / 64 | Floating ball, two-piece or three-piece construction | |
DN15-DN1000 | PN16 / 25 / 40 / 64 | Non-return valve, multiple body materials |
For projects that need both isolation and flow control, we combine API gate valves, API globe valves and ball valves in one order. Looking for corrosion-resistant fabricated or other stainless products? See our Stainless Steel Valve range.
A cast steel valve has a body (and usually a bonnet) made by casting steel to shape, then machining the sealing surfaces, flange faces and stem area. Casting makes it practical to produce the larger bores and higher pressure classes used in refineries, pipelines and power plants. Typical selection logic:
Choose cast steel over cast iron when the line has higher pressure, higher temperature, shock loads or hazardous media; cast steel has far better strength and ductility.
Choose cast steel over forged steel for sizes of about 2" and above and for complex body shapes; forged steel valves (such as API 602 designs) are normally used for small bores.
Choose gate valves for on/off isolation, globe valves for throttling and flow regulation, ball valves for quick quarter-turn shutoff, and check valves to stop reverse flow.
Standard products cover API and DIN piping systems. Non-standard dimensions, special alloys and high-pressure designs fall under custom manufacturing.
Specification | Standard Range |
|---|---|
Valve Types | Gate, Globe, Ball, Swing Check, Dual Plate Check, Butterfly |
API Gate Valve Size | 1/2"-48" |
API Globe Valve Size | 1/2"-24" |
API Ball Valve Size | 1/2"-24" |
API Swing Check Valve Size | 1/2"-40" |
API Dual Plate Check Valve Size | 2"-32" |
API Pressure Classes | Class 150 / 300 / 600 / 900 / 1500 |
DIN Ball Valve Size | DN15-DN300 |
DIN Check Valve Size | DN15-DN1000 |
DIN Pressure Ratings | PN16 / 25 / 40 / 64 |
Cast Carbon Steel | ASTM A216 WCB |
Low-Temperature Steel | ASTM A352 LCB |
Alloy Steel | ASTM A217 WC6 / WC9 |
Cast Stainless Steel | ASTM A351 CF8 / CF8M / CF3 / CF3M |
End Connections | Flanged / Butt Weld |
Operation | Handwheel / Lever / Gear |
Valve Trim | 13Cr, 304, 316 |
Bonnet / Cover | Bolted Bonnet / Bolted Cover |
Packing | Flexible Graphite |
Surface Protection | Standard finishes by product |
Inspection | API 598 for applicable API models |
SOLID supplies cast carbon steel, low-temperature steel, alloy steel and cast stainless steel valves in commonly specified ASTM grades.
Material Grade | Type | Typical Temperature Range* | Typical Use | SOLID Supply |
|---|---|---|---|---|
ASTM A216 WCB | Cast carbon steel | -29 to 425 °C | Oil, gas, water and general process piping | Gate, Globe, Ball, Swing Check, Dual Plate Check |
ASTM A216 WCC | Cast carbon steel | -29 to 425 °C | Projects specifying WCC | Custom |
ASTM A352 LCB | Low-temperature cast steel | -46 to 345 °C | Cold-climate and low-temperature pipelines | Gate, Globe, Ball, Swing Check |
ASTM A352 LCC | Low-temperature cast steel | -46 to 345 °C | Low-temperature service requiring LCC | Custom |
ASTM A217 WC6 | Cr-Mo alloy steel | -29 to 593 °C | Steam, power and elevated-temperature piping | Gate, Globe, Ball, Swing Check |
ASTM A217 WC9 | Cr-Mo alloy steel | -29 to 593 °C | High-temperature process and power piping | Gate, Globe, Ball, Swing Check |
ASTM A217 C5 / C12 | Cast alloy steel | Per project | Special elevated-temperature service | Custom |
ASTM A351 CF8 | Cast stainless (304 type) | Down to cryogenic, per rating | Water treatment, process piping, mild corrosive media | Gate, Globe, Ball, Check |
ASTM A351 CF8M | Cast stainless (316 type) | Down to cryogenic, per rating | Chemical processing, chloride-bearing media | Gate, Globe, Ball, Check |
ASTM A351 CF3 / CF3M | Low-carbon cast stainless | Per rating | Projects specifying low-carbon castings | Applicable Gate, Globe, Ball, Check |
Duplex / Nickel Alloy | Special cast alloy | Per project | Specialized corrosion-resistant service | Custom |
WCB: the default choice for non-corrosive oil, gas, water and steam at moderate temperature.
LCB / LCC: use when the minimum design temperature is below about -29 °C and impact toughness is required.
WC6 / WC9: use for high-temperature steam and power service where carbon steel loses strength.
CF8 / CF8M: use for corrosive or hygiene-sensitive media. CF8M (316 type) resists chlorides better than CF8 (304 type).
CF3 / CF3M: low-carbon versions that limit intergranular corrosion after welding.
Our ASTM A216 WCB gate, globe, ball and check valves cover oil, gas, water and process pipelines in Class 150, 300, 600, 900 and 1500, with flanged and butt-weld ends. For pipeline isolation, see our WCB API gate valves with bolted bonnet, OS&Y and rising-stem design.
ASTM A352 LCB gate, globe, ball and swing check valves are available for low-temperature industrial service. LCC is available as a custom material.
WC6 and WC9 gate, globe, ball and swing check valves serve elevated-temperature piping, with C5 and C12 available for custom projects. For steam and flow regulation, see our alloy steel globe valves with multiple pressure classes, trim materials and actuator options.
Stainless gate, globe, ball and check valves are available within the applicable API range.
Configuration | Standard Options | Custom Options |
|---|---|---|
Gate Valve Connections | Flanged / Butt Weld | RF / RTJ, special weld ends |
Globe Valve Connections | Flanged / Butt Weld | Special flange and weld ends |
Ball Valve Connections | Flanged | Project-specific ends |
Swing Check Connections | Flanged / Butt Weld | Special dimensions |
Dual Plate Check Connections | Wafer | Project-specific flange compatibility |
Butterfly Valve Connections | Wafer / Lug / Flanged | Special flanges |
Gate / Globe Operation | Handwheel / Gear | Electric / Pneumatic Actuators |
Ball Valve Operation | Lever / Worm Gear | Electric / Pneumatic Actuators |
Check Valve Operation | Automatic | Special internal configurations |
Component | Available Materials / Configurations |
|---|---|
Valve Stem | 13Cr, 304, 316, applicable alloys |
Seat / Seating Surface | Carbon steel, stainless steel, Stellite hardfacing |
Gate / Disc | Carbon steel, alloy steel, stainless steel |
Packing | Flexible graphite, special packing |
Gaskets | Standard industrial gaskets, custom materials |
Dual Plate Check Springs | Inconel / 17-7PH |
Dual Plate Check Shafts | F6a, 304, 316, 304L, 316L, 17-7PH |
Our API 594 dual plate check valves use Inconel or 17-7PH springs. For flanged or butt-weld non-return service we also supply cast steel swing check valves in WCB, LCB, WC6, WC9 and stainless steel.
Valve Type | Design Standards | Connection / Dimension Standards | Inspection |
|---|---|---|---|
Gate Valve | API 600 / ASME B16.34; API 6D where applicable | ASME B16.10 / B16.5 / B16.25 | API 598 |
Globe Valve | BS 1873 / ASME B16.34; API 623 where applicable | ASME B16.10 / B16.5 / B16.25 | API 598 |
Ball Valve | API 6D / ASME B16.34 / BS 5351 | ASME B16.10 / B16.5 | API 6D / API 598 |
Swing Check Valve | BS 1868 / ASME B16.34; API 6D where applicable | ASME B16.10 / B16.5 / B16.25 | API 598 |
Dual Plate Check Valve | API 594 / ASME B16.34 | API 594 / ASME B16.5 / B16.47 | API 598 |
Butterfly Valve | API 609 / ASME B16.34 | API 609 / ISO 5752 | API 598 / ISO 5208 |
DIN Check Valve | Applicable DIN requirements | DIN 3202 | DIN 3230 |
Our API 600 gate valves are offered with flanged and butt-weld ends; our API 594 check valves use wafer construction in multiple classes. For DIN projects we supply DIN ball valves and DIN check valves in PN16, PN25, PN40 and PN64.
SOLID builds custom valves for equipment manufacturers, distributors, EPC contractors and project buyers, including manufacturing to customer drawings and technical specifications.
Custom Item | Available Options |
|---|---|
Size | Non-standard dimensions and project configurations |
Pressure Class | Class 2500 for applicable high-pressure designs |
Carbon / Low-Temp Steel | WCC, LCC and project-specified grades |
Alloy Steel | WC1, WC6, WC9, C5, C12 and other applicable grades |
Stainless / Special Alloys | CF8, CF8M, CF3, CF3M, duplex, nickel alloys |
Trim | Stainless trim, hardfaced seats, special disc and stem materials |
Connections | RF, RTJ, butt weld, special flange dimensions |
Operation | Electric and pneumatic actuators |
Construction | Pressure seal bonnet, special disc and sealing designs |
Coating | Abrasive blasting, epoxy coating, protective primers and finish coats, specified colors |
Marking | OEM logo, product identification, project tag numbers |
Inspection / Documents | Additional NDE, third-party inspection, specified documentation |
Industry / Application | Valve Products | Common Materials |
|---|---|---|
Oil & Gas Pipelines | Gate, Ball, Swing Check | WCB, LCB, applicable alloy steel |
Petrochemical Processing | Gate, Globe, Ball, Check | WCB, WC6, WC9, CF8, CF8M |
Power Generation | Gate, Globe, Swing Check | WCB, WC6, WC9 |
Industrial Steam Systems | Gate, Globe, Check | WCB, WC6, WC9 |
Water Treatment | Gate, Ball, Check, Butterfly | WCB, CF8, CF8M |
Chemical Processing | Globe, Ball, Check | CF8, CF8M, special alloys |
General Industrial Piping | Gate, Globe, Ball, Check | WCB, stainless grades |
For non-return service, API swing check valves suit flanged or butt-weld lines, while dual plate check valves suit compact wafer installations.
We supply cast steel gate, globe, ball, swing check, dual plate check and butterfly valves in API and DIN series, with different sizes, pressure classes, body materials and end connections. Orders may combine several valve types.
WCB (ASTM A216) is the general-purpose carbon steel grade for ambient and moderate-temperature service. LCB (ASTM A352) is a low-temperature carbon steel with required impact toughness, used when the design temperature falls below about -29 °C.
Yes. WCB gate, globe, ball and check valves are available in Class 150, 300 and 600, with Class 900 and 1500 across our published API ranges, in flanged and other applicable connections.
Yes. Class 2500 is part of our custom range for suitable high-pressure designs, including high-pressure globe valves and applicable gate, ball and check valves.
Yes. We combine different material grades in one industrial order, including WCB, LCB, WC6/WC9 and CF8/CF8M, with additional materials for OEM and custom projects.
API 600 covers bolted-bonnet steel gate valves for general refinery and industrial service. API 6D covers pipeline valves, including slab and through-conduit gate designs. Tell us the project specification and we will quote the correct design.
Yes, for suitable gate, globe, ball and butterfly valves. Handwheel, lever and gear operation are also available.
SOLID supplies API and DIN cast steel valves to distributors, EPC contractors, equipment manufacturers and pipeline projects worldwide: WCB gate valves, LCB low-temperature valves, WC6/WC9 alloy valves, ball, globe and check valves, in standard Class 150-1500 and customized high-pressure options.
Send your valve list or specification (see the RFQ checklist above) and our sales team will prepare a quotation covering valve types, materials, pressure classes, quantities and configurations.
