Ductile Iron Ball Valve

Ductile Iron Ball Valve Manufacturer and Supplier

Solid Valve is a professional Ball Valve Manufacturer and trusted Ball Valve Supplier specializing in high-performance Cast Iron Ball Valve and Ductile Iron Ball Valve solutions for global industrial and municipal applications. As an experienced China Ball Valve Manufacturer, we produce durable Flanged Ball Valve products designed for water supply, wastewater treatment, and industrial pipeline systems.

Our Industrial Ball Valve is engineered with high-strength ductile iron or cast iron body, stainless steel ball and stem, and PTFE sealing seat to ensure zero leakage and long service life. This epoxy coated ductile iron ball valve provides excellent corrosion resistance, making it an ideal Water Supply Ball Valve and municipal water ball valve supplier solution.

As a leading ductile iron valve manufacturer and cast iron ball valve supplier china, we offer reliable PN16 PN25 Ball Valve and Full Bore Ball Valve products for demanding industrial environments.

Product Description

Body Material: Cast Iron or Ductile Iron

Ball and Stem Material: Stainless Steel

Full Port or Reduced Port Design

Bolted Bonnet and Split Body

Coating: Epoxy Coating or Paint Coating

Size Range: NPS 2” ~ 10”  ;  DN15 ~ DN250

Pressure Rating: Class 125  ;  PN10 / PN16

End Type: FF and RF

Mode of Operation: Handle Lever, Wrench nut, Pneumatic, etc.

Technical Specifications

Design and Manufacture: ASME B16.34  or  DIN 3357

Face to Face Dimensions: ASME B16.10  or  DIN 3202 F4 / F5

Flange Ends Dimensions: ASME B16.1  or  DIN 2533

Inspection & Test: API 598  or  DIN 3230

Top Mounting Pad Standard: ISO 5211

· Standard: DIN3357, API 6D, JIS 7S-48

· Type: Full bore, flanged end/ Reduce bore, flanged end

· Material: Ductile iron GGG50/40 or cast iron, stem: stainless steel 2CR13, ball: 2CR13 or SS 304, seat: PTFE

· Coating: Internal and external with fusion bonded epoxy coating.

Key Features of Industrial Ductile Iron Ball Valves

• High-strength body ensures long-lasting Industrial Ball Valve performance

• Stainless steel ball ensures reliable sealing in Cast Iron Ball Valve

• PTFE seat ensures zero leakage sealing

• Fusion bonded epoxy coated Ductile Iron Ball Valve resists corrosion

• Low torque operation improves efficiency

• Full Bore Ball Valve ensures maximum flow capacity

• Long service life with minimal maintenance

• Available as manual or automated Flanged Ball Valve

Applications of Water Supply and Industrial Ball Valves

This industrial ductile iron ball valve for water is widely used in municipal and industrial pipeline systems. As a professional municipal water ball valve supplier, our products ensure safe and reliable flow control.

• Municipal water supply systems

• Wastewater treatment plants

• Industrial pipeline systems

• HVAC systems

• Fire protection pipelines

• Irrigation systems

• Power plants

• Chemical plants

Why Choose Solid Valve as your China Ball Valve Manufacturer?

• Professional Ball Valve Manufacturer with global export experience

• Trusted cast iron ball valve supplier china

• Reliable PN16 ductile iron ball valve manufacturer

• Strict quality control and pressure testing

• Competitive factory price from direct Ball Valve Supplier

• Fast delivery worldwide

• OEM and ODM support

• Full technical support

Types of Flanged Ball Valves

• Full Bore Ball Valve

• Reduced Bore Cast Iron Ball Valve

• Gear Operated Ductile Iron Ball Valve

• Pneumatic Industrial Ball Valve

• Electric actuated Flanged Ball Valve

• Manual lever operated Water Supply Ball Valve

OEM Service from Professional Ball Valve Supplier

As a leading China Ball Valve Manufacturer and reliable Ball Valve Supplier, we provide customized valve solutions:

• Custom pressure rating including PN10, PN16 PN25 Ball Valve

• Custom epoxy coated Ductile Iron Ball Valve

• Custom flange standards

• OEM branding

• Custom packaging

Request Quote from Cast Iron Ball Valve Manufacturer

If you are looking for a reliable Cast Iron Ball Valve or Ductile Iron Ball Valve, Solid Valve is your trusted Ball Valve Manufacturer and global Ball Valve Supplier. We provide high-quality Flanged Ball Valve and Water Supply Ball Valve solutions with competitive pricing.

Contact us today to get the best quotation from a professional ductile iron flanged ball valve manufacturer and experienced PN16 ductile iron ball valve manufacturer.
